Description
Applicable Standards:
– High-Performance Data Cable
– 600MHz Bandwidth for Data Applications, Fast Ethernet and 155Mbps TP-PMD/CDDI
– Category-6 Shielded Twisted Pair
– Easily Identified Color-Striped Pairs
– 23AWG Solid Copper Conductors
– Exceeds TIA/EIA-568C.2, ISO/IEC 11801
– CAN/CSA -C22.2 No. 214
– ETL Listed, RoHS Compliant
Conductor:
23 AWG solid bare copper
Insulation:
HDPE
Shield:
AL Foil
Jacket:
LLDPE (UV)
-40°C to +70°C
Color Code:
– Pair 1: Blue-White/Blue
– Pair 2: Orange-White/Orange
– Pair 3: Green-White/Green
– Pair 4: Brown-White/Brown
Part# EKNB-2313
